| Velikost | Širina platišča (inch) | Zunanji premer (inch) | Širina odseka (inch) | Nosilnost – Tovorno kolo (kg) | Nosilnost – Krmilno kolo (kg) |
|---|---|---|---|---|---|
| 3.00 x 4 (R) |
2.10 / 2.50 | 9.9 | 3.3 | 260 | 195 |
| 3.50 x 4 (R) |
2.5 | 9.9 | 3.5 | 260 | 195 |
| 3.50 x 4 (R) |
2.5 | 10 | 3.5 | 260 | 195 |
| 4.00 x 4 (R) |
2.5 | 11.8 | 3.6 | 525 | 410 |
| 300 x 100 (S) |
2.75 | 12 | 4.1 | 850 | 650 |
| 3.20 – 8 (R) |
3 | 8.9 | 4.05 | 770 | 590 |
| 4.00 x 8 (R/Y) |
3.00 / 3.75 | 16 | 3.9 | 950 | 730 |
| 5.00 x 8 | 3.00 / 4.50 /3.50 (Y) / 3.75(W) |
17.9 | 4.9 | 1420 | 1090 |
| 140 / 55 – 9 |
4 | 15.4 | 5.6 | 1170 | 900 |
| 15 x 4 ½ – 8 (125/75 – 8) |
3.00 / 3.25 | 15.2 | 4.5 | 1040 | 800 |
| 16 x 6 – 8 (150/75 – 8) |
4.33 | 16 | 6.4 | 1495 | 1150 |
| 18 x 7 – 8 (180/70 – 8) |
4.33 | 18 | 5.9 | 2145 | 1650 |
| 18 x 9 – 8 | 7 | 18 | 8 | 2300 | 1900 |
| 21 x 8 – 9 (200/75 – 9) |
6 | 20.7 | 7.6 | 2755 | 2120 |
| 20 x 6 – 9 (S) |
4 | 19.45 | 5.5 | ||
| 20 x 8 x 9 (S) |
6 | 19.45 | 7.5 | ||
| 4.00 x 9.75 (R) |
3.75 | 16.8 | 4.8 | ||
| 200 / 50 – 10 |
6.5 | 17.8 | 7.4 | 2470 | 1900 |
| 23 x 9 – 10 (225/75 – 10) |
6.5 | 22.5 | 8.3 | 3445 | 2650 |
| 6.50 x 10 | 5 | 22.7 | 6.3 | 2340 | 1800 |
| 6.50 x 10 | 5.5 | 22.7 | 6.3 | 2570 | 1975 |
| 7.50 x 10 | 5.5 | 25.7 | 7.1 | 3070 | 2360 |
| 560 x 165 x 11 |
5 | 21.7 | 6.44 | ||
| 23 x 10 – 12 (250/60 – 12) |
8 | 23.3 | 9.65 | 3770 | 2900 |
| 7.00 x 12 | 5 | 25.4 | 6.9 | 2920 | 2240 |
| 27 x 10 – 12 (250/75 – 12) |
8 | 25.6 | 9.8 | 3900 | 3000 |
| 28 x 12.5 x 15 (355/45 – 15) |
9.75 | 27.1 | 12.4 | 5525 | 4250 |
| 32 x 12.1 x 15 (355/65 – 15) (350 – 15) |
9.75 | 32.28 | 11.8 | 7800 | 6000 |
| 250 x 15 (250/70 – 15) |
7 | 28.9 | 9.3 | 4750 | 3650 |
| 300 x 15 (315/70 – 15) |
8 | 32.3 | 10.1 | 5850 | 4500 |
| 6.00 x 15 | 4.5 | 27.4 | 5.9 | 2455 | 1820 |
| 7.00 x 15 | 5.50 / 6.00 | 27.6 | 7.5 | 3545 | 2725 |
| 7.50 x 15 | 5.50 / 6.00 / 6.50 | 28.3 | 7.5 | 3900 | 3000 |
| 8.15 x 15 (225/75 – 15) (28 x 9 – 15) |
7 | 27.1 | 8.4 | 3445 | 2650 |
| 8.25 x 15 | 5.50 / 6.50 | 30.7 | 7.9 | 4750 | 3650 |
| 7.50 x 16 | 5.50 / 6.00 | 30.8 | 7.9 | 3908 | 2831 |
| 8.00 x 16 | 5.5 | 3965 | 3050 | ||
| 8.25 x 16 | 6 | 30.75 | 8 | ||
| 7.50 x 20 | 6 | 34.75 | 7.05 | 3840 | 3200 |
| 8.25 x 20 | 6.50 / 7.00 | 38.9 | 9.1 | 4400 | 3675 |
| 9.00 x 20 | 7.00 / 7.50 / 8.00 | 40.4 | 9.5 | 5340 | 4450 |
| 10.00 x 20 | 7.50 / 8.00 | 40.4 | 9.5 | 6000 | 5000 |
| 11.00 x 20 | 7.50 / 8.00 | 41.4 | 10.35 | 6510 | 5245 |
| 12.00 x 20 – 42 |
8 | 41.4 | 10.35 | 6510 | 5245 |
| 12.00 x 20 – 43 |
8.00 / 8.50 | 43.4 | 11.6 | 7500 | 6250 |
| 14.00 x 20 (S) |
10 | 48.8 | 13.1 | 8250 | 6800 |
| 12.00 x 24 | 8.50 (S) / 10.00 (Y) | 47 | 11.8 | 8040 | 6650 |
| 14.00 x 24 | 10 | 51.2 | 13.2 | 11000 | 9175 |
